Frontier Rotor R-A6x50/13MI and Adapters

Category Accessories
Manufacturer Ohaus

Frontier rotors extend the functionality of Frontier centrifuges by increasing the number of tubes of varied types and sizes that can be used in conjunction with each of the centrifuge models. Easy to clean and operate, the rotors are durably constructed to withstand demanding centrifugation.

R-A6x50/13MI Rotor

Maximum Speed 13,000 rpm
Maximum Relative Centrifuge Force (x g) 15,869 g
Maximum Capacity (Rotor) 6 x 50 ml
Tube diameter without adapter 29mm / 50ml
Outer/Inner Radius 84 mm
Rotor Style Angle
Aerosol tight Not applicable
Acceleration Time (sec) 40 / 446
Angle 26°
Compatible Models FC5718; FC5718R; FC5816; FC5816R
Deceleration Time (sec) 30 / 1,323
Dimensions (LxØ) 6.77 in (172 mm)
Maximum loading weight 564 g
Multiple Maximum Speeds Yes
Net Weight 8.74 lb (3.96 kg)
Working Environment -4°F – 122°F, 95%RH, non-condensing (Temperature: -20ºC – 50ºC, Humidity: < 95%)

Available Adapters:

  • D17mm, 15ml Tubes x2 Adapter
  • D18mm, 16ml Tubes x2 Adapter
  • D26mm, 30ml Tubes x2 Adapter
  • D17.5mm 1x15ml FA 2/pk Adapter


select from options below to see SKU
